"Black Belt" is a pinball machine released by Bally in July 1986, featuring a martial arts theme. It has four flippers, one ramp, and does not include a multiball mode. Designed by Dan Langlois with artwork by Greg Freres, it is a solid-state machine built on the Bally MPU 6803 system. A total of 600 units were produced.
On the floor at 6 locations
1986 print with letter-size schematic pages
Playfield assembly illustrations with part lists
September 1986 bulletin on adding percent options
Includes power module drawings and solenoid expander
Mentioned in passing in 1 podcast
